24V 50Ah LiFePO4 Battery With F1 Connector

24V 50Ah LiFePO4 Battery With F1 Connector

24V 50Ah LiFePO4 Battery

24V LiFePO4 Battery

50Ah LiFePO4 Battery

Place of Origin:

China

Brand Name:

XWELL

Certification:

UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Model Number:

XW-LAR256120

Contact Us

Request A Quote
Product Details
Nominal:
50Ah
MAX Charge Voltage:
29.2V
Type:
Lithium-Ion Battery Pack
Battery Configuration:
8S And 2P
Cell Name:
Prismatic Cell
Nominal Voltage:
12.8V
DC Resistance:
≤10mΩ
Terminal Type:
F1 Connector
Cover Sealing Type:
Screw / Gel Sealing Optional
Waterproof:
IP65
Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Price
negotiable
Packaging Details
Carton
Delivery Time
7-10 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
5000 pcs per month
RELATED PRODUCTS
Contact Us
Product Description

24V 50Ah LiFePO4 Battery


Manly Battery offer high-quality 24V LiFePO4 battery for replacing lead acid battery. 24V 50Ah LiFePO4 battery supports 3 year warranty and Bespoke service. Furthermore, we offer a variety of certifications, such as UN38.3, IEC62133, UL, and CE, to ensure compliance with safety and quality standards.
Energy Storage
Solar-Wind Power System / City Grid (On/Off) / Community and Household

Lithium Battery Replacement Lead-Acid Specification


Model25.6V50Ah25.6V100Ah25.6V120Ah
Nominal Voltage25.6V
Nominal Capacity @25C50AH100AH120AH
Nominal Energy @25°C1280WH2560WH3072WH
Battery Cell TypePrismatic 50AhPrismatic 100AhPrismatic 120Ah
Configuration(xSxP)8S1P8S2P8S2P
Max.Continous Charge Current @25°C7A12A50A
Max. Continous Discharge Current @25°C7A12A50A
DC Resistance≤10mΩ
Full Charged Voltage29.2V
Discharge Cut-off Voltage20V
Operate Temperature RangeCharge: 0°C~55°C; Discharge: -20°C~60°C; Storage: -20°C~45°C
Dimension (mm)326x171x215mm522x240x218mm522x240x218mm
Weight(KG)12.5KG25KG28KG
Teminal TypeF1 terminalScrew teminal
Cover Sealing typeScrew / gel sealing optional
WaterproofIP65
Cyde life100% DOD Cycles @ 25xC 1C/1C: >2000 times80% DOD Cycles @ 25C 1C/1C: >6000 times50% DoD Cycles @ 25C, 1C/1C: >5000 times
LCD Screen DisplayOptional(Show voltage V,Power %)
BluetoothOptional (Bluetooth with mobile APP)
Series and Parallels FunctionAvailable to make in series and parallels to get 24V, 36V, 48V
Heating FunctionOptional, Suitable for cold area application


Why choose us?

Xwell is a national high-tech company focusing on lithium-ion battery packaging, design, production and sales.
The company was established in June 2017 with a registered capital of 5 million yuan.

The company has passed ISO 9001:2015 quality management system certification ISO14001:2015 environmental management system certification, QC080000 hazardous substance management system certification. The products have passed CE, CQC, RoHS, UN38.3, BIS and other certifications.
We adhere to the continuous independent innovation ability, excellent development and design ability and reasonable business positioning to provide customers with solutions to meet their different product needs. The company's business scope covers household energy storage, outdoor energy storage power supply, commercial energy storage system, photovoltaic energy storage system, security, medical treatment, precision instruments, intelligent travel, artificial intelligence, electric tools, unmanned aerial vehicles, ships 3C consumer electronics and other new energy fields.With efficient management.
Relying on efficient management, reasonable price and perfect techni- cal support,we strive to become a leader in the energy storage industry and creat high-quality energy storage products to bring users a better experience.



24V 50Ah LiFePO4 Battery  With F1 Connector 0
