Name: 5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery
Brand: XWELL
SKU: XW-5120W-1
Rating: 4.7 (131 reviews)

Home > products > Rackmount Lithium Battery >

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery

50ah Lifepo4 Battery Cabinet

200ah Lifepo4 Battery Cabinet

100ah Lifepo4 Battery Cabinet

Place of Origin:

China

Brand Name:

XWELL

Certification:

UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Model Number:

XW-5120W-1

Document:

Product Brochure PDF

Request A Quote

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery

Product Details

Model:

Rack Mounted Battery

Name:

XWELL

Pack Capacity:

50Ah 100Ah 200Ah

Pack Energy:

2.56Kwh 5.12Kwh 10.24Kwh (Optional)

Discharge Current:

50A

Max Charge Current:

50A

Discharge Cut-off Voltage:

42.5V

Display:

LCD Optional

Communication Interface:

RS485, RS232, CAN

Cycle Life:

>6000 Cycles(80%DOD)

Payment & Shipping Terms

Minimum Order Quantity

1 pcs

Packaging Details

Carton

Delivery Time

7-10 working days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

5000 pcs per month

RELATED PRODUCTS

86-186-2049-2985

sales@esslithiumbattery.com

86-186-2049-2985

Contact Now

Product Description

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery

Rack Mounted Battery adopts modular design, higher integration, and saves installation space; adopts high-performance lithium iron phosphate cathode material, good battery core consistency; various forms of communication interfaces, CAN/RS485, etc. can be based on Customized according to customer needs to facilitate the flexible use of system remote monitoring. High-energy, low-power lithium battery equipment achieves higher energy supply, lower energy consumption, and reduces environmental pollution; adopts all-round, multi-level battery protection strategies and fault isolation measures to ensure the safe operation of the system.

Rackmount Lithium Battery Specification

Model	51.2V50Ah	51.2V100Ah	51.2V200Ah
Nominal voltage	51.2V
Nominal capacity (kwh)	2.56	5.12	10.24
Cell type	LiFePO4
Standard charge voltage	54.6V(adjustable)
Max charge current	50A
Discharge cut-off voltage	42.5V(adjustable)
Max discharge current	50A
Display	LCD(Optional)
Communication interface	CAN/RS485/RS232
Cycle life	>6000 Cycles (80%DOD)
Charge temperature range	0~45°C
Discharge temperature range	-20~60°C
Color	Black
Dimension (mm)	442x410x133 3U	442x410x177 4U	550x442x220 5U
Weight	About 35Kg	About 42Kg	About 84Kg
Installation method	Rack Mount

Cell Specification of Rackmount Lithium Battery

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery 0

Operation Pannel of Rackmount Lithium Battery

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery 1

Size of Rackmount Lithium Battery

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery 2

Structure of Rackmount Lithium Battery

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery 3

Application of Rackmount Lithium Battery

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery 4

What We Offer?

Supply chain solution, strict quality control, real-time response
OEM/ODM Manufacturer, custom sizes and shapes available on request
Suggestion of new design or material, new technology and cost structure
Engineers team at your service
Flexible small orders are acceptable
One-stop supply to eliminating messy links

5kw 10kw 48v 50ah 100ah 200ah Lifepo4 Battery Cabinet Server Rack Mount Lithium Ion Phosphate Battery 5
