Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall

5KWh Rack Mounted LiFePO4 Battery

Rack Mounted LiFePO4 Battery

10KWh Rack Mounted LiFePO4 Battery

Place of Origin:

China

Brand Name:

XWELL

Certification:

UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Model Number:

XW-5120W-1

Document:

Product Brochure PDF

Request A Quote

Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall

Product Details

Battery Type:

Lithium Ion, LiFePO4

Battery Capacityion:

5KWH 100Ah Each Layer

Pack Capacity:

50Ah 100Ah 200Ah

Pack Energy:

2.56Kwh 5.12Kwh 10.24Kwh (Optional)

Discharge Current:

50A

Max Charge Current:

50A

Discharge Cut-off Voltage:

42.5V

Display:

LCD Optional

Communication Interface:

RS485, RS232, CAN

Cycle Life:

>6000 Cycles(80%DOD)

Payment & Shipping Terms

Minimum Order Quantity

1 pcs

Packaging Details

Carton

Delivery Time

7-10 working days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

5000 pcs per month

RELATED PRODUCTS

86-186-2049-2985

sales@esslithiumbattery.com

86-186-2049-2985

Contact Now

Product Description

Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall

1.Energy Storage --Solar-Wind Power System / City Grid (On/Off) / Community and Family 2.Back-up System and UPS --Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment 3.Other Applications --Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light --RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard / Electric bike / Electric Scooter / Electric bicycle --LED Backup / Engine Starting Battery,etc

Rackmount Lithium Battery Specification

Model	51.2V50Ah	51.2V100Ah	51.2V200Ah
Nominal voltage	51.2V
Nominal capacity (kwh)	2.56	5.12	10.24
Cell type	LiFePO4
Standard charge voltage	54.6V(adjustable)
Max charge current	50A
Discharge cut-off voltage	42.5V(adjustable)
Max discharge current	50A
Display	LCD(Optional)
Communication interface	CAN/RS485/RS232
Cycle life	>6000 Cycles (80%DOD)
Charge temperature range	0~45°C
Discharge temperature range	-20~60°C
Color	Black
Dimension (mm)	442x410x133 3U	442x410x177 4U	550x442x220 5U
Weight	About 35Kg	About 42Kg	About 84Kg
Installation method	Rack Mount

Cell Specification of Rackmount Lithium Battery

Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall 0

Operation Pannel of Rackmount Lithium Battery

Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall 1

Size of Rackmount Lithium Battery

Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall 2

Structure of Rackmount Lithium Battery

Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall 3

Application of Rackmount Lithium Battery

Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall 4

What We Offer?

Supply chain solution, strict quality control, real-time response
OEM/ODM Manufacturer, custom sizes and shapes available on request
Suggestion of new design or material, new technology and cost structure
Engineers team at your service
Flexible small orders are acceptable
One-stop supply to eliminating messy links

Energy Storage System Stackable Lithium Battery Rack Mounted LiFePO4 5KWh 10KWh 15KWh Solar ESS Power Wall 5
