24V 25.6V 100ah ESS Lithium Battery Deep Cycle Prismatic Type Cell

24V 25.6V 100ah ESS Lithium Battery Deep Cycle Prismatic Type Cell

100ah ESS Lithium Battery

25.6V ESS Lithium Battery

Prismatic deep cycle lithium battery

Place of Origin:


Brand Name:



UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Model Number:


Contact Us

Request A Quote
Product Details
Battery Capacity:
50 100 120AH
Battery Energy:
1280 2560 3072WH
Battery Configuration:
8S1P 8S2P
Battery Cell:
Prismatic Type Cell Battery
Max Charge Current:
Nominal Voltage:
DC Resistance:
Terminal Type:
F1 Connector
Cover Sealing Type:
Screw / Gel Sealing Optional
Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Packaging Details
Delivery Time
7-10 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
5000 pcs per month
Contact Us
Product Description

Custom-Made 24V 25.6V 100ah Deep Cycle Lithium Battery For Solar UPS ESS Lithium Battery


ESS Lithium Battery Features

1. Your can read the battery data throughcomputer, bluetooth, mobile phone.
2. You can read the battery data on computer: single cell voltage, capacity, temperature,cycles, etc.
3. You can read battery data on cell phone: include single cell voltage, capacity, current, battery pack total voltage, total capacity, temperature, cycles, etc.


ESS Lithium Battery Functions


1. Over charge protection(to prevant batteryovercharging)
2. Over current protection(to prevant batteryover current)
3. Short circuit protection(Automatically Cut offand Recovery)
4. Over discharge protection(to prevant batteryover discharging)
5. Over temperature protection(to prevant a high temp.and ensure a safe life)
6. Cell balancing function(to balance the single cellvoltage and ensure a longcycle life)


Lithium Battery Replacement Lead-Acid Specification


Model 25.6V50Ah 25.6V100Ah 25.6V120Ah
Nominal Voltage 25.6V
Nominal Capacity @25C 50AH 100AH 120AH
Nominal Energy @25°C 1280WH 2560WH 3072WH
Battery Cell Type Prismatic 50Ah Prismatic 100Ah Prismatic 120Ah
Configuration(xSxP) 8S1P 8S2P 8S2P
Max.Continous Charge Current @25°C 7A 12A 50A
Max. Continous Discharge Current @25°C 7A 12A 50A
DC Resistance ≤10mΩ
Full Charged Voltage 29.2V
Discharge Cut-off Voltage 20V
Operate Temperature Range Charge: 0°C~55°C; Discharge: -20°C~60°C; Storage: -20°C~45°C
Dimension (mm) 326x171x215mm 522x240x218mm 522x240x218mm
Weight(KG) 12.5KG 25KG 28KG
Teminal Type F1 terminal Screw teminal
Cover Sealing type Screw / gel sealing optional
Waterproof IP65
Cyde life 100% DOD Cycles @ 25xC 1C/1C: >2000 times80% DOD Cycles @ 25C 1C/1C: >6000 times50% DoD Cycles @ 25C, 1C/1C: >5000 times
LCD Screen Display Optional(Show voltage V,Power %)
Bluetooth Optional (Bluetooth with mobile APP)
Series and Parallels Function Available to make in series and parallels to get 24V, 36V, 48V
Heating Function Optional, Suitable for cold area application


Our Advantages

Professional Technical Team, Xwell's R&D technical team has recievedmore than 20 invention and applicationpatents.

Professional Sales Team, xwell poccesses well-trained sales team which helps customers addressing difficulty meeting in battery or battery solution selecting.

Unique Pack Technique, xwell possesses special pack techinique to better protect the battery and increase the life span of the battery pack.

Puntual Delivery, xwell has strict production plan to promise on time delivery.

Safety Certification Gurantee, Most products have been certified according to international standard including CE,MSDS,UN38.3.etc.

Perfect after Sales-service, xwell has a professional QC team which applies strict quality controlon production and provide perfect after-sale service to customers
