Rechargeable Lithium Battery Lead Acid Replacement , 24v 50ah Lithium Ion Battery IP65

Rechargeable Lithium Battery Lead Acid Replacement , 24v 50ah Lithium Ion Battery IP65

Rechargeable Lithium Battery Lead Acid Replacement

50ah Lithium Battery Lead Acid Replacement

24v 50ah Lithium Ion Battery IP65

Place of Origin:

China

Brand Name:

XWELL

Certification:

UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Model Number:

XW-LAR256120

Contact Us

Request A Quote
Product Details
Nominal Capacity:
50 To 120AH
Nominal Energy:
1280 To 3072WH
Configuration:
8S1P To 8S2P
Cell:
Prismatic Type Cell
Max Charge Current:
50A
Nominal Voltage:
12.8V
DC Resistance:
≤10mΩ
Terminal Type:
F1 Connector
Cover Sealing Type:
Screw / Gel Sealing Optional
Waterproof:
IP65
Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Price
negotiable
Packaging Details
Carton
Delivery Time
7-10 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
5000 pcs per month
RELATED PRODUCTS
Contact Us
Product Description

Rechargeable LiFePO4 25.6V 50Ah 100Ah 120Ah Lithium Ion Battery 24V Battery For Lead Acid Battery Replacement



Easy to replace lead acid battery



Xwell Lithium iron phosphate battery BMS also allows the battery can be charged fully with standard lead-acid characteristic curves charger, which means replacement for original lead acid battery become easy. However, we suggest you buy our matched Lithium iron phosphate battery charger to achieve 2 hour fully charge ability .



Fast charging ability



Xwell lithium iron phosphate batteries can be easily fully-charged within a very short time due to large amps charging acceptance. it is able to accept up to 1C (1 x rated capacity) continuous charging amps which makes the battery can be fully charged within 2 hour. this feature will greatly improve the load service efficiency .





Lithium Battery Replacement Lead-Acid Specification



Model 25.6V50Ah 25.6V100Ah 25.6V120Ah
Nominal Voltage 25.6V
Nominal Capacity @25C 50AH 100AH 120AH
Nominal Energy @25°C 1280WH 2560WH 3072WH
Battery Cell Type Prismatic 50Ah Prismatic 100Ah Prismatic 120Ah
Configuration(xSxP) 8S1P 8S2P 8S2P
Max.Continous Charge Current @25°C 7A 12A 50A
Max. Continous Discharge Current @25°C 7A 12A 50A
DC Resistance ≤10mΩ
Full Charged Voltage 29.2V
Discharge Cut-off Voltage 20V
Operate Temperature Range Charge: 0°C~55°C; Discharge: -20°C~60°C; Storage: -20°C~45°C
Dimension (mm) 326x171x215mm 522x240x218mm 522x240x218mm
Weight(KG) 12.5KG 25KG 28KG
Teminal Type F1 terminal Screw teminal
Cover Sealing type Screw / gel sealing optional
Waterproof IP65
Cyde life 100% DOD Cycles @ 25xC 1C/1C: >2000 times80% DOD Cycles @ 25C 1C/1C: >6000 times50% DoD Cycles @ 25C, 1C/1C: >5000 times
LCD Screen Display Optional(Show voltage V,Power %)
Bluetooth Optional (Bluetooth with mobile APP)
Series and Parallels Function Available to make in series and parallels to get 24V, 36V, 48V
Heating Function Optional, Suitable for cold area application



Our Advantages


Professional Technical Team, Xwell's R&D technical team has recievedmore than 20 invention and applicationpatents.

Professional Sales Team, xwell poccesses well-trained sales team which helps customers addressing difficulty meeting in battery or battery solution selecting.

Unique Pack Technique, xwell possesses special pack techinique to better protect the battery and increase the life span of the battery pack.

Puntual Delivery, xwell has strict production plan to promise on time delivery.

Safety Certification Gurantee, Most products have been certified according to international standard including CE,MSDS,UN38.3.etc.

Perfect after Sales-service, xwell has a professional QC team which applies strict quality controlon production and provide perfect after-sale service to customers
