Name: Rechargeable Lithium Battery Lead Acid Replacement , 24v 50ah Lithium Ion Battery IP65
Brand: XWELL
SKU: XW-LAR256120
Rating: 4.7 (172 reviews)

Home > products > Lithium Battery Lead Acid Replacement >

Rechargeable Lithium Battery Lead Acid Replacement , 24v 50ah Lithium Ion Battery IP65

Rechargeable Lithium Battery Lead Acid Replacement

50ah Lithium Battery Lead Acid Replacement

24v 50ah Lithium Ion Battery IP65

Place of Origin:

China

Brand Name:

XWELL

Certification:

UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Model Number:

XW-LAR256120

Document:

Product Brochure PDF

Request A Quote

Rechargeable Lithium Battery Lead Acid Replacement , 24v 50ah Lithium Ion Battery IP65

Product Details

Nominal Capacity:

50 To 120AH

Nominal Energy:

1280 To 3072WH

Configuration:

8S1P To 8S2P

Cell:

Prismatic Type Cell

Max Charge Current:

50A

Nominal Voltage:

12.8V

DC Resistance:

≤10mΩ

Terminal Type:

F1 Connector

Cover Sealing Type:

Screw / Gel Sealing Optional

Waterproof:

IP65

Payment & Shipping Terms

Minimum Order Quantity

1 pcs

Price

negotiable

Packaging Details

Carton

Delivery Time

7-10 working days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

5000 pcs per month

RELATED PRODUCTS

86-186-2049-2985

sales@esslithiumbattery.com

86-186-2049-2985

Contact Now

Product Description

Rechargeable LiFePO4 25.6V 50Ah 100Ah 120Ah Lithium Ion Battery 24V Battery For Lead Acid Battery Replacement

Easy to replace lead acid battery

Xwell Lithium iron phosphate battery BMS also allows the battery can be charged fully with standard lead-acid characteristic curves charger, which means replacement for original lead acid battery become easy. However, we suggest you buy our matched Lithium iron phosphate battery charger to achieve 2 hour fully charge ability .

Fast charging ability

Xwell lithium iron phosphate batteries can be easily fully-charged within a very short time due to large amps charging acceptance. it is able to accept up to 1C (1 x rated capacity) continuous charging amps which makes the battery can be fully charged within 2 hour. this feature will greatly improve the load service efficiency .

Lithium Battery Replacement Lead-Acid Specification

Model	25.6V50Ah	25.6V100Ah	25.6V120Ah
Nominal Voltage	25.6V
Nominal Capacity @25C	50AH	100AH	120AH
Nominal Energy @25°C	1280WH	2560WH	3072WH
Battery Cell Type	Prismatic 50Ah	Prismatic 100Ah	Prismatic 120Ah
Configuration(xSxP)	8S1P	8S2P	8S2P
Max.Continous Charge Current @25°C	7A	12A	50A
Max. Continous Discharge Current @25°C	7A	12A	50A
DC Resistance	≤10mΩ
Full Charged Voltage	29.2V
Discharge Cut-off Voltage	20V
Operate Temperature Range	Charge: 0°C~55°C; Discharge: -20°C~60°C; Storage: -20°C~45°C
Dimension (mm)	326x171x215mm	522x240x218mm	522x240x218mm
Weight(KG)	12.5KG	25KG	28KG
Teminal Type	F1 terminal		Screw teminal
Cover Sealing type	Screw / gel sealing optional
Waterproof	IP65
Cyde life	100% DOD Cycles @ 25xC 1C/1C: >2000 times80% DOD Cycles @ 25C 1C/1C: >6000 times50% DoD Cycles @ 25C, 1C/1C: >5000 times
LCD Screen Display	Optional(Show voltage V,Power %)
Bluetooth	Optional (Bluetooth with mobile APP)
Series and Parallels Function	Available to make in series and parallels to get 24V, 36V, 48V
Heating Function	Optional, Suitable for cold area application

Our Advantages

Professional Technical Team, Xwell's R&D technical team has recievedmore than 20 invention and applicationpatents.

Professional Sales Team, xwell poccesses well-trained sales team which helps customers addressing difficulty meeting in battery or battery solution selecting.

Unique Pack Technique, xwell possesses special pack techinique to better protect the battery and increase the life span of the battery pack.

Puntual Delivery, xwell has strict production plan to promise on time delivery.

Safety Certification Gurantee, Most products have been certified according to international standard including CE,MSDS,UN38.3.etc.

Perfect after Sales-service, xwell has a professional QC team which applies strict quality controlon production and provide perfect after-sale service to customers
