Place of Origin:
China
Brand Name:
XWELL
Certification:
UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE
Model Number:
XW-LAR256120
Contact Us
Deep Cycle Solar Lithium Ion Battery To Replace Gel AGM 12V 100ah 120ah 150ah 200ah 250ah Lead Acid Battery
Lithium Battery Replacement Lead-Acid Description
Lead-acid batteries are widely used, but because of their high maintenance costs, short battery life and great environmental pollution, they are gradually replaced by lithium ion batteries. Lithium iron phosphate battery with the same volume has higher energy density and lighter weight, which is the best alternative to lead acid. It is small in size and light in weight which made it more convenient.
It can be used in Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts.
Lithium Battery Replacement Lead-Acid Specification
| Model | 25.6V50Ah | 25.6V100Ah | 25.6V120Ah |
| Nominal Voltage | 25.6V | ||
| Nominal Capacity @25C | 50AH | 100AH | 120AH |
| Nominal Energy @25°C | 1280WH | 2560WH | 3072WH |
| Battery Cell Type | Prismatic 50Ah | Prismatic 100Ah | Prismatic 120Ah |
| Configuration(xSxP) | 8S1P | 8S2P | 8S2P |
| Max.Continous Charge Current @25°C | 7A | 12A | 50A |
| Max. Continous Discharge Current @25°C | 7A | 12A | 50A |
| DC Resistance | ≤10mΩ | ||
| Full Charged Voltage | 29.2V | ||
| Discharge Cut-off Voltage | 20V | ||
| Operate Temperature Range | Charge: 0°C~55°C; Discharge: -20°C~60°C; Storage: -20°C~45°C | ||
| Dimension (mm) | 326x171x215mm | 522x240x218mm | 522x240x218mm |
| Weight(KG) | 12.5KG | 25KG | 28KG |
| Teminal Type | F1 terminal | Screw teminal | |
| Cover Sealing type | Screw / gel sealing optional | ||
| Waterproof | IP65 | ||
| Cyde life | 100% DOD Cycles @ 25xC 1C/1C: >2000 times80% DOD Cycles @ 25C 1C/1C: >6000 times50% DoD Cycles @ 25C, 1C/1C: >5000 times | ||
| LCD Screen Display | Optional(Show voltage V,Power %) | ||
| Bluetooth | Optional (Bluetooth with mobile APP) | ||
| Series and Parallels Function | Available to make in series and parallels to get 24V, 36V, 48V | ||
| Heating Function | Optional, Suitable for cold area application | ||
Our Advantages
Professional Technical Team, Xwell's R&D technical team has recievedmore than 20 invention and applicationpatents.
Professional Sales Team, xwell poccesses well-trained sales team which helps customers addressing difficulty meeting in battery or battery solution selecting.
Unique Pack Technique, xwell possesses special pack techinique to better protect the battery and increase the life span of the battery pack.
Puntual Delivery, xwell has strict production plan to promise on time delivery.
Safety Certification Gurantee, Most products have been certified according to international standard including CE,MSDS,UN38.3.etc.
Perfect after Sales-service, xwell has a professional QC team which applies strict quality controlon production and provide perfect after-sale service to customers
