Place of Origin:
China
Brand Name:
XWELL
Certification:
UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE
Model Number:
XW-2560W-1
Contact Us
Intelligent Monitoring With BMS Customization A-Grade 2.56kwh 5.12kwh 10.24kwh ESS Lithium Battery 20Ah 100Ah 200Ah
Advantages of ESS Lithium Battery
Morning: Optimized self-consumption will be achieved. Batteries are used to store the excess energy produced by PV systerm
Afternoon: Extra energy will be fed into the grid when batteries are fully charged and system has already met its self consumption requirement.
Evening: Batteries will power the AC load when the sun sets.
Night: If the battery capacity is insufficient to meet self consumption,electricity will be obtained from the grid
Application of ESS Lithium Battery
1. Off-grid Solar ESS
2. Marine /Yatch
3. Night Fishing Power
4. RV/ Camper Power
5. Camping Power Supply
6. Solar Street Light
Features of ESS Lithium Battery
Easy installation
Light weight
Compact size
Industrial And Commercial Energy Storage System Specification
| Model | 51.2V50Ah | 51.2V100Ah | 51.2V200Ah |
| Nominal voltage | 51.2V | ||
| Nominal capacity (kwh) | 2.56 | 5.12 | 10.24 |
| Cell type | LiFePO4 | ||
| Standard charge voltage | 54.6V(adjustable) | ||
| Max charge current | 50A | ||
| Discharge cut-off voltage | 42.5V(adjustable) | ||
| Max discharge current | 50A | ||
| Display | LCD(Optional) | ||
| Communication interface | CAN/RS485/RS232 | ||
| Cycle life | >6000 Cycles (80%DOD) | ||
| Charge temperature range | 0~45°C | ||
| Discharge temperature range | -20~60°C | ||
| Color | Black | ||
| Dimension (mm) | 442x410x133 3U |
442x410x177 4U |
550x442x220 5U |
| Weight | About 35Kg | About 42Kg | About 84Kg |
| Installation method | Rack Mount | ||
Cell Specification of ESS Lithium Battery
Operation Pannel of ESS Lithium Battery
Size of ESS Lithium Battery
Structure of ESS Lithium Battery
Application of ESS Lithium Battery
