Solar Rackmount Lithium Battery 2.56Kwh 51.2V 50Ah With LiFePO4 Prismatic Cell

Solar Rackmount Lithium Battery 2.56Kwh 51.2V 50Ah With LiFePO4 Prismatic Cell

Rackmount Lithium Battery 2.56Kwh

Rackmount Lithium Battery 51.2V

Place of Origin:

China

Brand Name:

XWELL

Certification:

UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Model Number:

XW-2560W-1

Contact Us

Request A Quote
Product Details
Voltage:
51.2V
Capacity:
2.56kwh
Cell:
LiFePO4 Prismatic
Discharge Current:
50A
Standard Charge Voltage:
54.6V
Max Charge Current:
50A
Discharge Cut-off Voltage:
42.5V
Display:
LCD Optional
Communication Interface:
RS485, RS232, CAN
Cycle Life:
>6000 Cycles(80%DOD)
Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Packaging Details
Carton
Delivery Time
7-10 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
5000 pcs per month
RELATED PRODUCTS
Contact Us
Product Description

2.56Kwh 51.2V 50Ah Sacolar LFP Cells Rackmount Solar Battery Pack Lithium Battery For Solar ESS Lithium Battery



Description of ESS Lithium Battery



Intelligent anti-theft solution achieved via software lock, buzzer alarm, gyroscopeand GPS, the last two of which are optional.
Operating temperature ranges from -20℃ to 55℃. In cold area with temperature less than 0℃, the battery supports low temperature heating (optional).Expandability: a maximum of 16 batteries can be parallel-connected.
Compact Design: 19 inch rack, 3.0U height volume energy density((VED)2160 Wh/L
Safety performance: state-of-the-art LFP cell and reliable BMS design.



Features of ESS Lithium Battery



1. Reliable Automotive Grade lithium iron Phosphate Battery, Higher energy density, stable performance & greater power
2. Long Cycle Life, 6000-8000 times, 10-15YRS service time
3. Low Resistance & High Current, Low self-discharge rate & Efficient charging
4. Match Multiple Brands Inverter, Simultaneous communication & docking with multiple brands inverter
5. Intelligent BMS Battery Protection, Effectively avoiding overcharge, Overdischarge, Overcurrent,Short-circuit
6. Good Safety Performance, 100% safe, Extreme safety test





Industrial And Commercial Energy Storage System Specification



Model 51.2V50Ah 51.2V100Ah 51.2V200Ah
Nominal voltage 51.2V
Nominal capacity (kwh) 2.56 5.12 10.24
Cell type LiFePO4
Standard charge voltage 54.6V(adjustable)
Max charge current 50A
Discharge cut-off voltage 42.5V(adjustable)
Max discharge current 50A
Display LCD(Optional)
Communication interface CAN/RS485/RS232
Cycle life >6000 Cycles (80%DOD)
Charge temperature range 0~45°C
Discharge temperature range -20~60°C
Color Black
Dimension (mm) 442x410x133
3U
442x410x177
4U
550x442x220
5U
Weight About 35Kg About 42Kg About 84Kg
Installation method Rack Mount



Cell Specification of ESS Lithium Battery



Solar Rackmount Lithium Battery 2.56Kwh 51.2V 50Ah With LiFePO4 Prismatic Cell 0



Operation Pannel of ESS Lithium Battery



Solar Rackmount Lithium Battery 2.56Kwh 51.2V 50Ah With LiFePO4 Prismatic Cell 1

Size of ESS Lithium Battery



Solar Rackmount Lithium Battery 2.56Kwh 51.2V 50Ah With LiFePO4 Prismatic Cell 2



Structure of ESS Lithium Battery



Solar Rackmount Lithium Battery 2.56Kwh 51.2V 50Ah With LiFePO4 Prismatic Cell 3



Application of ESS Lithium Battery



Solar Rackmount Lithium Battery 2.56Kwh 51.2V 50Ah With LiFePO4 Prismatic Cell 4
