Stackable Home Battery Modular 48v 10.24kwh Lifepo4 Lithium Ion Home Solar System Energy Storage Battery
Powerful compatibility, widely used
1. Modular Power: UPS, Back-up power, Base Transceiver Station, Power Tool
2. Network Power: GPS products, monitoring units, tracking units, DC switching power supply system
3. Transportation Power: E-bike, E-scooter, Golf cartmotorcycle
Features of Stackable Home Battery
1. ≥5000 cycles @ 25°C DOD 70%.
2. Built-in autonomous fire extinguishing system.
3. Easy to install, supports stackbable parallel connection of up to 6 modules, and simply stacks more modules for more capacity.
4. Compatible with most major PV inverters, such as Growat, SRNEMUST, Deye, GOODWE, SOFAR, Victron Energy...
5. Advanced technology is adopted. When multiple batteriesare connected in parallel, the system will automatically allocate backup batteries, which is different from other batteries.
6. With passive balancing for charging and also with active balancingfor parallel connections.
Stackable Home Battery Specification
| Model |
1 Module |
2 Modules |
3 Modules |
4 Modules |
5 Modules |
6 Modules |
| Nominal capacity(kwh) |
5.12 |
10.24 |
15.36 |
20.48 |
25.6 |
30.72 |
| Operating voltage |
48V |
| Weight (Kg) |
96.5 |
151.5 |
206.5 |
261.5 |
316.5 |
371.5 |
| Nominal voltage |
48V |
| Dimension (mm) |
600x460x457 |
600x460x637 |
600x460x817 |
600x460x997 |
600x460x1177 |
600x460x1357 |
| Battery cell type |
LiFePO4 |
| Communication method |
CAN/RS485/RS232 |
| Operating temperature range |
Charging: 0~45℃ Discharging: -10~50℃ |
| Protection level |
IP55 |
| Installation method |
Floor installation |
| Cycle life |
>6000 Cycles(80%DOD) |
| Peak charge/discharge current (@25℃ ,5S) |
100A |
| Self-discharge rate |
≤3.5%/month/@25°C |
| Parallel function |
1S~6S |
Stackable Home Battery Connection Diagram
FAQ
1. Is the battery used in the battery pack grade A?
Yes, we only use Grade A and Brand new cells inside.
2.Do you test and match the battery before installing the battery pack?
Yes, every cell will be tested capacity, IR, voltage to surely match
Voltage:The deviation less than 0.01V
Resistance:The deviation less than 0.1mΩ
Capacity: Same capacity matched
3.How do I store my batteries?
When the product is not in use for a long time, it should be stored in a dry, clean and well-ventilated warehouse at 10°C～35°C, avoiding inflammable and explosive materials; the battery pack should be charged and maintained regularly every three months to ensure that the battery best performance state.
4.What is the cycle life of the battery?
6000 cycle life @ 80% DOD
5.What's the warranty of your 48V/51.2V battery pack?
5 years warranty, if there is broken item under quality problem within warranty time, we will offer free replacements or refund, up to your needs
6.Do your batteries support series or parallel connection?
Our 48V battery packs support up to 15pcs in parallel, if you need series connection, please contact our sales staff
