Nominal Voltage ESS Lifepo4 Home Battery For Home Appliances

Nominal Voltage ESS Lifepo4 Home Battery For Home Appliances

ESS Lifepo4 Home Battery

Nominal Voltage Lifepo4 Home Battery

Place of Origin:

China

Brand Name:

XWELL

Certification:

UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Model Number:

XW-2560W

Contact Us

Request A Quote
Product Details
Material System:
Lithium Iron Phosphate
Max Charge Current:
40A
Maximum Discharging Current:
100A(2C)
Operating Voltage Range:
2.5-3.65V
Internal Impedance:
≤0.8mΩ
Dimension:
Width:135±1mm
Voltage:
40V
Maximum Discharge Current:
50A
Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Packaging Details
Carton
Delivery Time
7-10 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
5000 pcs per month
RELATED PRODUCTS
Contact Us
Product Description

ESS Lithium Battery Nominal Voltage Home Appliances Home Energy Storage Lifepo4 Battery



 Description

ESS lithium batteries are designed to store large amounts of electrical energy for long periods of time, and they are typically used in conjunction with renewable energy sources to provide backup power during times of low or no energy production. They can be configured in a variety of ways, including as standalone systems or as part of a larger grid-connected energy storage system.

Nominal Voltage ESS Lifepo4 Home Battery For Home Appliances 0

Nominal Voltage ESS Lifepo4 Home Battery For Home Appliances 1



Home Energy Storage System Specification



No. Item General Parameter Remark
1 Material system Lithium iron phosphate /
2 Typical Capacity 50Ah 0.5C Standard discharge
3 Operating voltage range 2.5~3.65V /
4 Nominal Voltage 3.2V Mean Operation Voltage
5 Standard Charge Voltage 3.6V



By standard charge method

6 Internal Impedance ≤0.8mΩ 1kHz;2%SOC
7 Dimension Thickness: ≤37.5mm



Initial Dimension

Width:135±1mm
Hight:192±1mm
8 Weight ≤2.03 Kg
9 Standard charge current 0.5C 0.5C constant current,3.65V constant voltage charge to 3.65V, continue charging till current decline to ≤0.05C
10

Maximum Charging

Current

50 A 25±2℃
11 Standard discharge Current 0.5C 25±2℃
12 Maximum discharge current 50 A 25±2℃
13 Maximum Discharging Current 100A(2C) 25℃, 50%SOC, 30s





















































Home Energy Storage System Operation Pannel



Nominal Voltage ESS Lifepo4 Home Battery For Home Appliances 2



Home Energy Storage System Size



Nominal Voltage ESS Lifepo4 Home Battery For Home Appliances 3



Home Energy Storage System Single Battery Pack Wiring Diagram



Nominal Voltage ESS Lifepo4 Home Battery For Home Appliances 4



Home Energy Storage System Parallels Connection Wiring Diagram



Nominal Voltage ESS Lifepo4 Home Battery For Home Appliances 5



FAQ



Q: What is your MOQ?
A: There is no MOQ and we also support a sample service.



Q: How about the payment terms?
A: T/T, Paypal, Wire Transfer and Online Transfer are all acceptable.



Q: Is the battery kit equipped with BMS?
A: Yes, our battery kit comes complete with the BMS and all the accessories needed to assemble the battery pack. Customers can assemble their own battery packs if they have enough batteries.



Q: What options are available for the BMS that comes with the battery kit?
A: 100A/150A/200A BMS are availble for customers to choose.



Q: What are the advantages of your battery kits?
A: Our kits have the following advantages:
⭐Stackable
⭐External port can pass 250A current individually
⭐The internal BMS is compatible with CAN and RS485 communication and can communicate with a wide range of inverters without complex commissioning
⭐The PCB boards are soldered with the corresponding wires for the customer to assemble in order
⭐The external LCD display shows the basic parameters
⭐The side clamping plates apply pressure to the battery for better clamping
⭐Equipped with a weak switch for greater safety
⭐Complimentary 485 adapter cable for connection to the PC



Q: What is the shipping time limit for battery kit?
A:The transit time is approximately 35-38 business days.



Q: What should I do when I receive the battery kits?
A: First open the box when you sign for it to check that the contents have not been damaged in transit, and then double check that the battery kit is complete with all the accessories.



Q: Why has my logistics information not been updated?
A: The goods will be shipped by UPS or a local shipping company, but due to the tedious process of shipping across borders, the logistics information will not be updated for a while until the goods arrive in your country. It is only when the goods are picked up by the local carrier and ready for dispatch that the logistics status will be updated accordingly.

feature

1.Carefully selected 16pcs batterycells the smaller the voltagedifference between the individualcells the higher the utilizationrate of the battery , the longer life.
2.100%Full Capacity
3.Monitor the voltage and currentof the BMS, and clearly see thebattery cycle times.
